Description
TECHNOLOGY
Passionate about quality sound reproduction for more than 30 years, we have listened to, compared and experienced all the speaker technologies existing on the market: electrodynamics, high efficiency, electrostatic, ribbons in different forms, flat diaphragm speakers rigid… etc. Each of these technologies have undeniable qualities, but we are convinced that the one that brings together the most advantages and allows music to be reproduced most naturally are isodynamic loudspeakers, also called Magnetostatic.
THE ADVANTAGES OF ISODYNAMIC TECHNOLOGY
- Diffusion over a large area by plane wave, which allows for immersive listening without sound projection effect
- Dipole operation, on both sides of the speakers, to recreate the spatialization of the concert in your listening room.
- The use of extremely thin mylar membranes (12µm) for high speed and no drag effect.
- The same type of diaphragm used from bass to treble, everything works at the same speed which provides consistency in dynamic behavior across the spectrum.
- No box behind the speaker; there is no “box sound” associated with the midrange buzz in the speaker. The timbres of the voices and instruments are perfectly respected
- Consistent, balanced and detailed listening even at low levels.
- A regular impedance which does not represent a complex load on the amplifier.
- High reliability over time, our speakers are not afraid of dust or humidity, they do not have a high voltage circuit.
EXCLUSIVE DIPTYQUE TECHNOLOGIES
The isodynamic technology well known to music lovers was developed in 1970 in the United States. Through our numerous tests and experiments, we have sought solutions to improve this technology and push back its limits, in particular for bass reproduction.
- PPBM®: Push Pull Bipolar Magnet is an innovative patented architecture. The large section bipolar magnets, manufactured to specification, are located at the front and rear of the diaphragm. They make it possible to maintain the coil (aluminum tapes) in a constant magnetic field when the membrane moves, which is thus perfectly controlled. The bass is more dynamic and transient sounds are reproduced with precision. Listening to a grand piano is impressively realistic.
- A Mechanical Sandwich Structure. Composed of the assembly of 3 different materials: MDF frame, fine felt and stamped sheets held in force by a mechanically welded steel frame. This set is perfectly rigid and not reasoning, it is a mechanical reference which guarantees the absence of coloring and the respect of the timbres.
- Proprietary ribbon tweeters. The ribbon is produced as an isodynamic cell (mylar film and aluminum coil). It moves in an intense magnetic field made from neodymium magnets. These tweeters operate over a wide frequency range and mate perfectly with isodynamic cells. A simple crossover (6 db per octave) allows a perfect fusion of the registers. The highs are soft, precise and spin high to give a sublime soundstage.
SPECIFICATIONS | |
Type | 2-way |
Sensitivity | 86db/1W/1m |
Impedance | 6 Ohms |
Bandwidth | 40 – 19000Hz |
Power handling | 150 W (recommended amplifier > 60 W) |
Dimensions (height / width / depth) | 42″ H x 18.5″ W x 0.78″ D 1070x470x20 mm) |
Weight / with stand | 48.5 Lbs / 22 Kg ea. |
On-Mag,fr July 2015 –
“Diptyque Audio: isodynamic panels made in France with a level of mastery worthy of the greatest.
In Hi-Fi, on the acoustic panel market, the chosen ones are few and often installed for very many decades, such as Martin Logan and Magneplanar. However, the French brand Diptyque Audio, thanks to its perseverance since 2001, is beginning to become a key player in this field. It has now reached a level of technical mastery worthy of the greatest.” On-Mag,fr July 2015
René van Es, HiFi.NL July 2021 –
“The sound image with the DP107 is bigger, deeper, wider and more imposing than the DP77 while the character has remained the same. All Diptyque characteristics are reflected in this system, enlarged and further developed. It is really the sound of a good electrostat or magnestostat that I hear. Anyone who can fit a DP107 and keep space behind the speakers can hardly think of anything better. Lack of layer? Certainly not. Control in the layer? Certainly.” René van Es, HiFi.NL July 2021
Christian Punter, HFA January 2022 –
“No doubt, the DP-107’s owe a good deal of their fantastic performance to the tweeter’s Neodymium magnets and the woofer’s Push-Pull Bipolar Magnet technique. For one, this makes it possible to produce bass of this quality and depth from a relatively small panel, and second, it enables a level of expression and immediacy that I have not yet heard from other ribbon speakers.” Christiaan Punter HFA January 2202
